Zycoo CooFone-D60 - Telephone IP Ecran Rétro-Eclairé 2 Lignes de SIP PoE
Chargement... Fiche Technique
Description du Produit
The Fanvil X3P IP Phone is an industrial masterpiece, offering superior user experience and simplicity for home and office users with elegant appearance and intelligent software.
Main Features
Call out / answer / reject
Mute / Unmute (microphone)
Call Hold / Resume
Call Waiting
Intercom
Caller ID Display
Call Forwarding (Always/Busy/No Answer)
Call Transfer (Attended/Unattended)
Call Parking/Pick-up (depending on server)
Redial
Do-Not-Disturb (per line / per phone)
Auto-Answering (per line)
Voice Message (on server)
Local 3-way Conference
Hot Line
Specifications
Generic
2 SIP Lines
HD Voice
User Friendly Graphical Menu with Help description
POE Enabled (X3P)
Handset (HS) / Hands-free (HF) / Headphone (HP) mode
Desktop / Wall-mount installation
External Power Supply (X3)
Economical and Environmental friendly package
Industrial Standard Certifications: CE/FCC
Call Features
Call out / answer / reject
Mute / Unmute (microphone)
Call Hold / Resume
Call Waiting
Intercom
Caller ID Display
Call Forwarding (Always/Busy/No Answer)
Call Transfer (Attended/Unattended)
Call Parking/Pick-up (depending on server)
Redial
Do-Not-Disturb (per line / per phone)
Auto-Answering (per line)
Voice Message (on server)
Local 3-way Conference
Hot Line
Phone Features
Initialization Configuration Wizard
Up to 5 User Accounts / Profiles with individual phonebook/call log/configurations/PIN
Phone Accessibility Control by User PIN
Intelligent Phonebook (up to 500 entries total)
Cloud Phonebook (XML)
Intelligent Contact Number Matching / Filtering
Call log (300 entries total, in/out/missed)
Call Connection Quality (QoS) Measurement and Indication
Voice Message Waiting Indication (VMWI)
Network Time Synchronization
Audio
HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
Wideband ADC/DAC 16KHz Sampling
Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB
Wideband CODEC: G.722
Full-duplex Acoustic Echo Canceller (AEC) – Hands-free Mode, 96ms tail-length
Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)
Packet Loss Concealment (PLC)
Dynamic Adaptive Jitter Buffer up to 300ms
DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO Networking
Physical: 10/100Mbps Ethernet, dual bridged port for PC bypass
IP Configuration: Static / DHCP / PPPoE
Network Access Control: 802.1x
VPN: L2TP (Basic Unencrypted) / OpenVPN
VLAN
QoS
Protocols
SIP2.0 over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
PPPoE
802.1x
L2TP (Basic Unencrypted)
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
TR069
RFCs:
354/1321/1350/1769/1889/1890/2131/2132/2616/ 2617/2661/2833/2976/3261/3262/3263/3264/3265/ 3268/3311/3489/3711/4346/4566/5630/5865
Deployment & Maintenance
Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR069
Web Management Portal
Web-based Packet Dump
Configuration Backup/Restore
Auto/Manual Online Software Upgrade
Syslog
Physical Specifications
LCD x1: 128x48 dot-matrix with backlit
Keypad: 25 keys, including
4 Soft-keys
12 Standard Phone Digits keys
2 Navigation keys (Up/Down)
2 Line keys with tri-color LED
1 Redial / Call Log Key
3 Volume Control keys, Up/Down/Mute(Microphone)
1 Hands-free / Headphone key
HD Hands-free Speaker (0 ~ 7KHz) x1
HD Hands-free Microphone (0 ~ 7KHz) x1
HD Handset (RJ9) x1
Standard RJ9 Handset Wire x1
1.5M CAT5 Ethernet Cable x1
RJ9 Phone Jacket x2: Handset x1, Headphone x1
RJ45 Ethernet Jacket x2: Network x1 (802.3AF POE Class 1 Enabled, X3P only), PC x1 (Bridged to Network)
Main Chipset: Broadcom
DC Power Input: 5V/1A
Power Consumption: Idle – ~ 1.1W, Peak – ~ 1.8W
Working Temperature: 0 ~ 40℃
Working Humidity: 10 ~ 65%
Dual-Functional Back Rack x1: Desktop Stand / Wall-mount
Color: Black (K) / White (W) / Red (R) / Blue (B) / Yellow (Y)
Package Dimensions: 275x215x62mm(W x H x L)
| Nbr, de lignes | 1 |
| Ports Ethernet | 2 |
| PoE | Oui |
| Protocole | SIP |
| BLF (DSS) | Non |
| Module d'extension | Oui |
| Interface Casque | Non |
| Ecran | LCD |
| Ecran rétroéclairé | Oui |
| Répertoire n° | 100 |
| Support MWI | Oui |
| WiFi | Oui |
| Bluetooth | Oui |
| Provisioning Method | HTTP, WEB GUI |
| Garanti | 1 ans |
