General

Type

VoIP gateway

Width

9.5 in

Depth

10 in

Height

2.1 in

Weight

2.4 lbs

Networking

Form Factor

External

Ports Qty

8

Connectivity Technology

Wired

Framing Format

G.711, G.723.1

Data Link Protocol

Ethernet, Fast Ethernet

Remote Management Protocol

SNMP 1, Telnet, HTTP

Communication Mode

Half-duplex, full-duplex

Status Indicators

Port status, collision status, link OK

Features

BOOTP support, manageable, Trivial File Transfer Protocol (TFTP) support

IP Telephony

VoIP Protocols

SIP

Voice Codecs

G.723.1, G.729ab, G.711u, G.711a, T.38

Telephony Interfaces

8 line (FXO)

Expansion / Connectivity

Interfaces

8 x phone line - RJ-45
1 x management
1 x network - Ethernet 10Base-T/100Base-TX - RJ-45

Miscellaneous

MTBF

5 years

Compliant Standards

EN 60950, EN55024, UL 60950 Third Edition, EN55022 Class B, ICES-003 Class B, IC CS-03, FCC Part 15 B, FCC Part 68, RoHS, CSA C22.2 No. 60950 Third Edition

Power

Power Device

Power adapter - externe

Voltage Required

AC 120/230 V ( 50/60 Hz )

Environmental Parameters

Min Operating Temperature

32 °F

Max Operating Temperature

104 °F
